High Def Video Smart Lock LS-C95
Frais d'expédition calculés à l'étape de paiement.
Information produit
Users who upgrade old locks need to pay attention to the following points:
1，Multi-directional measurement of old locks.(refer to the picture example)
1-1. Measure the size of the old lock panel.
We have many different sizes of smart locks, please refer to the product details for details, make sure the size of the smart lock you choose can replace the old lock. (1. New doors do not need to consider this. 2. Double-hole American doors recommend C87/C88 with traditional mechanical door handles)
1-2. Measure the distance between the center point of the old lock's mechanical keyhole and the edge of the door.
Models we support are:20xx，25xx，28xx，30xx，35xx，40xx，45xx，50xx，60xx，65xx，70xx，75xx.
1-3. Measure the distance between the center point of the old lock handle and the mechanical key hole.
Models we support are:xx50，xx68，xx72，xx85.*Single-tongue(#DS) lock bodies are not affected.
1-4. Measuring the old lock Mortise faceplate size.
*Mortise faceplate supports the 5050 lock body size of 145*23mm.
*default Mortise faceplate size for other lock bodies is 230*23mm.
*Single-tongue(#DS) lock bodies are not affected.
Please contact Locstar for manual processing after purchasing Mortise faceplate of other sizes! !
2，Measuring the thickness of the door. (refer to the picture example)
Door thickness we support is around 35-120mm. If your door thickness does not meet this requirement, please contact Locstar staff after purchase. They will manually adjust the screw length to ensure that the product can be installed and used normally after receipt!
3，Determine the direction of the lock handle. Right handle(A/B) Left handle(C/D). (refer to the picture example)
Currently, only the 8058/8072 models require confirmation of the handle installation direction before shipment. Other models do not require confirmation. We will upgrade and solve the problem as soon as possible!
When you visit here, I believe you must know some key data of your old lock, such as the size of lock panel,lock body model,Mortise faceplate size,door thickness, etc. After knowing these relevant information, you can choose the door lock that suits you. Of course, our installation is also very simple. We have a free manual. You can search Locstar on YouTube to check the door lock related videos. Remember to follow and subscribe to us. I believe you can also become an excellent locksmith.
Here, let us start a new smart extraordinary experience together! !
Locstar official team.
✔️ Backset
Distance between the edge of the door and the centre of the door lock.
✔️ Door Stile/Frame
The door stile/frame is the flat surface area where the smart door lock is mounted, and the minimum door stile refers to the minimum surface area required for a specific lock. Check the 'Fitment' section of each lock to find its minimum door stile requirement.
✔️ Mortise/Mortise Lock
A type of lock that is installed within a door, with the lock body embedded or recessed into a mortise pocket within the door. A mortise lock size usually refers to the Backset of that specific mortise.
For example, 'Swing - 28mm' = Mortise lock with a 28mm Backset for a Swing Door.
✔️ Latch
A spring-loaded mechanism that keeps the door closed when engaged and can be released by turning a doorknob or lever.
✔️ Deadbolt
A bolt that extends into the door jamb to prevent the door from being forced open.
✔️ Striker Plate/Strike Plate
The a metal plate that is installed on a door jamb or frame where the door latch or deadbolt extends into to keep the door securely closed.
✔️ Strike Box
The strike box is the plastic box installed behind the strike plate and is attached to the door frame with screws. When the door is closed, the latch or bolt on the lock extends into the strike plate box.
✔️ Keyless Entry
A feature that allows users to unlock a door without using a traditional key, typically using methods such as numeric keypads, fingerprint, or smartphone apps.
✔️ Keypad Entry
A type of keyless entry system that utilizes a numeric keypad for entering a PIN code to unlock the door.
✔️ Bluetooth Connectivity
A wireless communication technology that enables the smart lock to connect and communicate with other devices, such as smartphones or tablets. Bluetooth is short-range and usually about 3-7 meters.
✔️ Wi-Fi Connectivity
A wireless networking technology that allows the smart lock to connect to the internet, providing remote access and control capabilities.
Product Details
The High Def Video Smart Lock LS - C95 is a revolutionary home security product. It features a high - definition video camera with 1080p resolution and a wide - angle lens, allowing for clear real - time viewing of visitors at the doorstep, which is great for busy professionals and families keeping an eye on their home remotely.
There are multiple unlocking options, including a fingerprint scanner, a backlit keypad for PIN entry, a traditional keyhole for backup, and remote unlocking via the app.
Security is top - notch with a body made of high - grade, tamper - resistant materials, a reinforced deadbolt, and features like motion detection and tamper alerts that send immediate phone notifications.
Installation is easy with a comprehensive guide and all hardware included. It runs on a long - lasting rechargeable battery with low - battery app notifications.
Technical Parameter
【Triple Security Features】: Experience peace of mind with this keyless entry door lock, integrating rapid fingerprint recognition, a crisp 2K HD
camera, and a sophisticated video doorbell, ensuring your home's security is uncompromised.
【Remote Access and Real-Time Notifications】: Stay connected to your home with the TUYA WIFI Security app, offering No Monthly Fee for
remote door management and immediate notifications, so you're always informed, no matter where you are.
【Long-Lasting Battery Life and Robust Build】: Count on endurance and resilience with a 5,000 mAh battery and a sturdy design that's certified
to withstand extreme weather, from icy cold to scorching heat, ensuring reliability all year round for your keyless entry system.
【Easy Installation and Reliable Customer Support】: Set up the security system in just 15 minutes, compatible with US/Canadian deadbolts
without the need for drilling, and enjoy peace of mind with a 12-month warranty and 24/7 customer support.
| Bluetooth Standard | Bluetooth 5.0BLE | Fingerprint Head Type | Semiconductor fingerprint head |
| Network Connection | 2.4G WiFi 802.11b/g/n | Fingerprint Capacity | 100 pcs |
| Support Mobile Phone System | Android 4.3 or IOS7.0 or higher |
Recognition Rate(FAR) | < 0.001% |
| Power Supply Mode | 7.4V Lithium (full charge 8.4v) |
True Rejection Rate(FRR) | < 1.0% |
| Low Alarm Voltage | 7.0 V | Operating Temperature | |
| Voltage Range | 5~9V | Sensor | 2 million HD CMOS sensor color 0.1Lux@F1.2, black and white 0.01Lux@F1.2 |
| Standby Current | 550 microampere (including cat eye, radar, face) |
Image Output | Hd: 1960*1080@12fps |
| Smooth: 640*360@25fps | |||
| Working Current | < 3A (average) | Lens | Hd security mirror, 138° wide Angle, height 13±0.2mm |
| Key Type | Capacitive touch keys | Nearest Object Distance | 0.3m |
| Password Quantity | Custom and permanent password 250 |
Day-night Switching Mode | support |
| Other dynamic passwords are unlimited |
|||
| Supported Card Type | MIFARE M1 card | IR-CUT Voice Intercom | support |
| Number Of IC Cards | 1000 pcs | Mobile Phone Surveilllance | Support mobile monitoring (iOS, Android) |
| Unlocking Mode | App, password, fingerprint, IC card, wireless key |
Cloud Storage | support |
